Aluminum CNC Double Head Mitre Saw Machine Price

Aluminum CNC Double Head Mitre Saw Machine

Model: LJZ2-CNC-550*4500Z

☆ Mainly used for the cutting of aluminum profile /Aluminum pipes, aluminum bars/ aluminum curtain wall material,aluminum sections/ aluminum casing etc.

but also can be used for UPVC and wood profile.

☆ The machine adopts numerical control technology, and can complete the automatic positioning cutting of different specifications and sizes of profiles.

☆ Select high quality aluminum alloy/diamond saw blade, the outer diameter can reach 550mm, high line speed, high processing accuracy.

☆ CNC transmission adopts high standard rack and gear, high transmission accuracy, accurate positioning, smooth operation.

☆ High precision spindle makes the saw blade rotate stably and effectively improves the surface quality of the machining parts.

☆ The gas-liquid damping cylinder realizes uniform feed speed and smooth motion.

☆ Use a micro spray cooling device.

☆ Automatic head rotation, two-way positioning, clamping, can work independently with a single head. Automatic opening and closing of the protective cover make the operation safer.

☆ The saw blade is automatically set at 45° and 90° angles, and the protective cover is automatically opened and closed to make the operation safer.

☆ The saw blade is from the back to the front, which makes the profile cutting safer and more reliable, and the sawing height and width are very large.

☆ The absolute value servo upgrade memory function is not required to return to the reference when starting up.

☆ Printing function, support usb disk import data function.

Aluminum CNC Double Head Cutting Saw Machine
Power supply: 380V 50HZ/60HZ
Shaft motor: 2 x 3.00KW / 2840r/min
Private motor: 1.00KW
Working pressure: 0.5~ 0.8MPa
Gas consumption: 60L/min
Sawing length: Max4500mm min. 400mm
Sawing width: Max.350mm
Maximum cutting slope: 45°350×135mm 90°350×200mm
Sawing Angle: 90°,45°
Cutting speed: stepless speed adjustment 0-3m/min
Saw blade specification: ø550 x ø30 x 4.7 x Z144
Size: 6500 x 1750 x 1800 mm
Weight: 2300kg
Repeat fixed length accuracy: ±0.02mm
Profile cutting Angle tolerance: ± 3'
Cutting profile flatness: ± 0.02m
Cut surface roughness: Ra12.5μm
